Quick Details

  • Products Status: Stock
  • Type: Thermal transfer/Direct thermal
  • Style: Color
  • Use: Barcode Printer
  • Interface Type: USB
  • Max Paper Size: 104 mm(4.09") 1016mm(40")
  • Black Print Speed: Up to4 ips
  • Max. Resolution: 203dpi
  • Brand Name: TSC
  • Model Number: TSC TTP-244pro AS1415
  • Place of Origin: Guangdong, China (Mainland)
  • Resolution: 203 dpi
  • Printing Method: Thermal transfer
  • Max. Print Width: 104 mm(4.09inch)
  • Print Speed: Up to4 ips

Packaging & Delivery

Packaging Details: Export Carton
Delivery Detail: With 7days after payment
TSC TTP-244plus  Barcode Printer barcodes maker
TSC TTP-244plus  offers the following features:
  • 200 MHz 32-bit RISC processor with 8 MB DRAM,2MB FLASH memory
  • Internally Scalable True Type fonts
  • TSPL-EZ firmware emulates Eltron and Zebra
    languages out of the box
  • Dual-motor gear driven design
  • 300 meter ribbon supply on a 1” core (coated side out)
  • 4.3” OD internal media supply, optional external
    media unwinder supports 8” OD label rolls on 3” cores
  • 4 inches per second print speed
  • USB 2.0 & RS-232C interfaces
  • Free bundled labeling software and Windows drivers
  • All TSC printers feature an industry best 1 year limited warranty



Resolution

203 DPI
Printing Method
Thermal transfer
Print Speed
Up to4 ips
Max. Print Width
104 mm(4.09”)
Max. Print Length
1016mm(40”)
Enclosure
ABS plastic
Physical dimension
232mm W x 288mmL x 156mm H  (9.13" W x 11.34" L x 6.14" H)
Ribbon capacity
300(984 ft), 1”core, Max OD67mm
Label roll capacity
109.2 mm(4.3”) OD
Processor
32 bit RISC CPU
Ribbon
600 meter long, 1”core(ink coated outside or inside)
Ribbon width
25.4mm-114.3mm(1”-4.5”)
Processor
32-bit RISC CPU
Memory
2MB FLASH memory    2MB SDRAM
Interface
Standard RS-232(max.19,200bps)  USB 1.1 or Centronics(factory option)
Power
AC input:100-240V universal switching power supply   DC output:24v2A
 Operation switch, button
One power switch  Feed button and Pause button
 Sensors
Transmissive sensor, Reflective sensor, Ribbon end sensor
Internal font
8 alpha-numeric bitmap fonts, one true type font-CG triumvirate bold condensed
Code page
Codepage 850(Latin 1) Codepage 852(Latin2) Codepage860(Portuguese) Codepage 863(French Canadian) Codepage865(Nordic) Codepage857(Turkish) Codepage861(Iceland) Codepage1252(Latin1) Codepage1250(Latin2) Codepage1254(Turkish) Latin-1(ISO-8859-1:Western European) Latin-2(ISO-8859-2:Central European) Latin-9(ISO-8859:Turkish)
Bar code
1D bar code: Code39, Code 39C, Code 93,Code 128UCC,Code 128 subset A, B , C , Codabar, Interleave 2 of 5,EAN-8,EAN-13,EAN-128,UPC-A,UPC-E, EAN and UPC 2(5) digits add-on, MSI,PLESSEY,POSTINET, China Post, ITF14, EAN 14
2D bar code: PDF-417,Maxicode, DataMartix, QR Code
Font& barcode rotation
0, 90, 180, 270 degrees
Print language
TSPL2 TPLE TPLZ
Media type
continuous, die-cut, black mark, ticket, tag
Media wound type
Outside wound
Media width
25.4-114 mm(1”-4.4”)
Media thickness
0.06-0.25mm(2.36-9.84mil),
Media core diameter
25.4-76.2mm(1”-3”)
Label length
10-1016mm(0.4”-40”)
Environment condition
Operation: 5-40°C(41-104°F),25-85% non-condensing

Storage:-40-60°C(-40-140°F),10-90% non-condensing
Safety regulation
FCC Class A, CE Class A, C-Tick Class A, UL, CUL, TUV/GS,CCC
